HONEYWELL T6812DP08 LCD Digital Thermostat

Super modern appearance design, suitable foroffice, hotel and residential building
Independant installation on 86 size box directly
Big LCD with English and icon display
Easy to install and set-up
Selectable room temperature or setpoint display
Manual fan speed selection
Adjustment of display room temperature
Temperature unit either ํC or ํF
User setting can be kept when power off
Lock or unlock keys in Installer Set-up
Heat and cool setpoint limitation for energysaving

FREQUENCY	50/60Hz
INPUT CURRENT	4(2)A
CONTROL ALGORIYHM	PI, On/off output
RATING CAPACITY	220V: 4(2)A for fan load, 2(1)A for zone valve; 110V: 4(2)A for fan load, 2(1)A for zone valve
CYCLE TIMES	100,000
SETPOINT RANGE	10~32℃
INSTALLATION	Installed on 86×86mm junction box or US2×4 inch.
ACCURACY	+/-1℃ at 21℃
ENVIRONMENTAL CONDITIONS	Operation temperature -18~49℃ Shipping temperature -35~65℃ Relative humidity 5~90%
PROTECTION CLASS	IP20
ACTION TYPE	Action Type 1
POWER SUPPLY	T6811DP08: 110(+20%,-10%)VAC T6812DP08: 220(+/-10%)VAC
MAXIMUM TEMPERATUR	155℃
